ACM
Features:
Made from high-grade JBD6 (AC6) resin-bond diamond, this powder is produced using advanced techniques such as crushing, shaping, purification, and grading. It is light gray in color, features regular crystal morphology, low impurity and magnetic content, excellent self-sharpening, and a polycrystalline-like structure with tightly controlled shape and size distribution.
Applications:
Ideal for high-precision resin-bond abrasives, polishing pastes, and fluids. Commonly used in fine polishing of hard alloys, optical glass, and other applications demanding superior product quality.
|
 |
JGDM-D
Features:
Crafted from premium JRD resin-bond diamond, this powder is refined through precision crushing, shaping, purification, and grading. It has a light yellow-green color, relatively uniform crystals, low impurity levels, consistent particle size, and good self-sharpening ability.
Applications:
Suitable for resin and ceramic bond abrasives, as well as grinding pastes and fluids. Commonly used for polishing gemstones, ceramics, glass, optical glass, and hard alloys. A cost-effective solution with strong wear resistance and high grinding performance.
|
 |
JGDM-C
Features:
Made from high-quality JSD10 synthetic single-crystal diamond, this general-purpose powder is processed through advanced crushing, shaping, purification, and grading. It appears light yellow, with relatively uniform crystals, low impurities, weak magnetism, and consistent particle distribution.
Applications:
Applicable to metal, ceramic, and resin bond abrasives, as well as polishing pastes and fluids. Ideal for finishing gemstones, optical glass, ceramics, stones, and non-metallic materials like PCD and PCBN.
|
 |
JGDM-B
Features:
This high-strength powder is made from premium JSD20 single-crystal diamond and processed via advanced crushing, shaping, purification, and grading steps. It features a light yellow color, uniform crystal structure, low impurity levels, weak magnetism, and tightly controlled particle size distribution.
Applications:
Suitable for metal and ceramic bond abrasives, electroplated tools, and polishing compounds. Commonly used in precision grinding wheels for optical glass, fine pellets, edge wheels, sapphire grinding wheels for silicon, gemstone tools, and wire saws for slicing silicon and sapphire.
|
 |
JGDM-A
Features:
Derived from high-strength JSD30 single-crystal diamond, this powder is refined through advanced crushing, shaping, purification, and grading. It has a light yellow color, uniform crystal form, minimal impurities (low magnetism), high strength, narrow size distribution, excellent wear resistance, and good dispersion.
Applications:
Ideal for metal, ceramic, and electroplated bonded tools. Used in cutting, grinding, and polishing of brittle materials like silicon, sapphire, gemstones, quartz, LED substrates, LCD glass, and semiconductors.
|
